Board-to-Cable Connector for High Speed Differential Transmission

HDMI 2.1 Specification Approved HDMI作为电视机等影像设备的标准接口被大幅度的进行了普及。近年来，市场开始追求更加高清稳定真实的影像画面传输，在日本2018年12月实行新4K8K卫星广播之后，今后这种新型的方式也会被渐渐推广传播。在此情况下，航空电子研究开发了可以对应4K120Hz,8K60Hz, HDR(High Dynamic Range)等的HDMI 2.1新规范。 「DC04系列」是最早取得HDMI2.1规范许可的连接器种类。除了通过优化各通道端子位置来降低串扰，并通过模制触点来提高阻抗特性，并且确保了稳定的高速传输特性的质量。此外，壳体尖端的独特结构增加了电缆连接时的强度，提供了足够的坚固性能。 本公司从HDMI连接器的标准开发阶段就参与了HDMI论坛的讨论计划，为其的标准化建设作出了贡献。从今往后，我司也会继续扩大我们插座连接器以及线束电缆的阵容，为大家提供更为优质的服务。

TNC series middle size coaxial connectors conform to the general purpose standards (IEC60169-17), designed with threaded coupling. Applicable frequencies: from DC up to 3GHz. High performance with a V.S.W.R.(Voltage Standing Wave Ratio) of 1.2 or less. A wide variety of products enable various mounting styles. Environmental middle size connectors with rugged vibration proof construction. A high degree of reliability provides stable electric continuity and high frequency performance. Products applicable up to about 3GHz are available. For detail, please consult us. In addition to independent cable application type, we also harness products which satisfy your specification are available.
