Features 1612 size Low voltage operation Low phase noise Single package structure Applications Mobile phones GPS/GNSS and Industrial radio communications

Features 1008 size, height 0.13mm max. Unprecedented extremely low-profile package using a novel structure Composed only of quartz crystal plates and metallic films without the use of a ceramic base Long-term high resistance to aging, due to avoiding the use of an organic conductive adhesive Reduced risk of the inclusion of foreign matter due to assembly in a vacuum environment Applications Mobile communications and short-range wireless modules Wearable devices Automotive millimeter-wave radar

Features Fixed 32.768 kHz Smallest footprint in chip-scale (CSP): 1.5 x 0.8 mm ±5, ±10, ±20 x 10-6 frequency stability options over temp Ultra-low power: +990 nA (typ.) Internal filtering eliminates external Vdd bypass cap NanoDrive™ programmable output swing for lowest power Applications Smart meters Health and wellness monitors Pulse-per- second timekeeping RTC reference clock
